Dormakaba ITS 96 Concealed Door Closer BCA G 96 N Slide Arm EN 3-6

The Dormakaba ITS 96 Concealed Door Closer BCA G 96 N Slide Arm EN 3-6 is a premium concealed door closing system for modern architectural doors with reliable closing performance and a clean appearance. Part of the renowned Dorma ITS 96 range, this dormakaba door closer combines cam-action technology, adjustable closing force and hydraulic backcheck in a compact concealed design.

The G 96 N slide arm complements the concealed closer body to create a discreet solution for high-quality residential, commercial and architectural applications.

Dormakaba ITS 96 BCA G 96 N – Key Features

• Concealed Installation – The closer is integrated into the door and frame for a clean, minimalist appearance.
• EN 3–6 Adjustable Closing Force – Closing force can be continuously adjusted to suit different door requirements.
• Hydraulic Backcheck (BCA) – Provides controlled resistance when the door is opened forcefully, helping protect the door, wall and surrounding areas.
• G 96 N Slide Arm – Designed specifically for the ITS 96 concealed door closer system.
• EASY OPEN Technology – Cam-action technology helps provide a low opening force for easier everyday operation.
• Adjustable Closing Speed – Closing speed can be adjusted according to the requirements of the installation.
• Adjustable Latching Action – The latching action can be independently adjusted for controlled final closing.
• Concealed, Non-Handed Design – Suitable for a wide range of door configurations without requiring a left- or right-handed closer body.
• For Internal and External Applications – The BCA version is designed for a broad range of interior and outward-opening exterior door applications.
• Suitable for Heavy Doors – The EN 3–6 BCA version supports door leaves up to 180 kg, depending on the application and installation configuration.
• Door Width up to 1,400 mm – Suitable for compatible door leaves up to 1,400 mm wide.
• Approx. 120° Maximum Opening – Maximum opening angle depends on the door construction and installation conditions.

Concealed Door Closer for a Clean Architectural Finish

The Dorma concealed door closer concept is ideal for projects where conventional surface-mounted door closers would interfere with the appearance of the door. With the ITS 96 installed within the door and frame, the hardware remains discreet while the door continues to benefit from controlled automatic closing.

This makes the Dormakaba ITS 96 particularly suitable for prestige doors, contemporary interiors, offices, hotels, commercial buildings and other projects where architectural appearance is an important consideration.

The compact design also helps protect the door closer from accidental impact and tampering compared with exposed surface-mounted hardware.

Hydraulic Backcheck for Controlled Door Opening

One of the key differences of the ITS 96 BCA is its hydraulic backcheck function.

The backcheck becomes progressively stronger as the door is opened more rapidly. This helps prevent the door from being thrown open aggressively and provides additional protection for the door, adjacent walls, facade elements and people near the opening.

Unlike a simple mechanical door stop, the hydraulic backcheck provides controlled damping during opening. The system is therefore particularly useful in high-traffic environments and applications where doors may be opened with greater force.

EASY OPEN Technology for Easier Door Operation

The Dorma ITS 96 uses proven cam-action technology designed to provide a rapidly decreasing opening torque. This makes the door easier to open while maintaining controlled closing performance.

The EASY OPEN principle can be particularly useful in buildings where accessibility and ease of operation are important. It allows the door closer to combine dependable automatic closing with a more comfortable opening experience.

Adjustable Closing Performance

The Dormakaba door closer ITS 96 BCA provides several adjustment options to help installers fine-tune the door after installation.

The closing force can be continuously adjusted within the EN 3–6 range, while the closing speed and latching action can also be adjusted using the integrated controls.

This allows the closer to be configured according to the door size, weight, usage pattern and site conditions rather than relying on a fixed closing setting.

G 96 N Slide Arm for the ITS 96 System

The G 96 N slide arm is an integral part of the ITS 96 concealed door closer system. It provides the sliding-channel connection between the closer mechanism and the door while maintaining the discreet appearance associated with the ITS 96 range.

The G 96 N system is designed to work with the ITS 96 series and offers a clean alternative to traditional projecting closer arms.

For architects, interior designers and hardware professionals looking for a Dorma door closer concealed within the door and frame, the ITS 96 with G 96 N slide arm offers a practical combination of aesthetics and functionality.

Applications of Dormakaba ITS 96 BCA

The Dormakaba ITS 96 BCA G 96 N can be used in a wide range of applications where concealed door closing and controlled opening are required.

Typical applications include:

• Premium residential doors
• Office doors
• Hotel and hospitality projects
• Commercial buildings
• Institutional buildings
• Interior architectural doors
• Heavy-duty doors
• Compatible fire and smoke doors
• Outward-opening external doors
• Prestige architectural projects
• Single-leaf and compatible double-leaf door applications

The BCA version is particularly useful where protection against forceful door opening is required in addition to automatic closing.

Dormakaba ITS 96 BCA – Technical Specifications

Technical suitability should always be checked against the actual door construction, dimensions, weight, fire/smoke-door requirements and installation configuration.

Why Choose the Dormakaba ITS 96 BCA?

The Dorma ITS 96 is designed for applications where a conventional surface-mounted door closer is not desirable. Its concealed installation preserves the appearance of the door while providing dependable automatic closing.

The BCA version adds hydraulic backcheck, making it particularly useful where uncontrolled or forceful opening needs to be reduced. Combined with EASY OPEN technology and adjustable closing performance, it offers a balance between convenient everyday operation and controlled door movement.

For architects, builders, contractors and interior designers, the Dormakaba ITS 96 BCA G 96 N is a suitable solution when both aesthetics and door-control performance are important.

Dormakaba Door Closer for Premium Architectural Doors

If you are looking for a dorma concealed door closer for a modern architectural project, the ITS 96 BCA provides a discreet alternative to conventional overhead door closers. Its concealed construction keeps the door elevation clean, while the adjustable closing force, closing speed, latching action and hydraulic backcheck allow the system to be configured for the application.

The Dorma Kaba door closer range is widely associated with architectural door hardware and door-control solutions, and the ITS 96 continues this approach with an integrated design intended for high-quality doors.

Dorma Door Closer Price in India

The Dorma door closer price depends on the exact ITS 96 configuration, slide channel, accessories, finish, application and supply requirements. If you are comparing the Dorma door closer price for different ITS 96 configurations, it is important to compare the complete system—including the closer body, G 96 N slide arm/channel and any required accessories—rather than comparing the closer body alone.

Buy Dormakaba ITS 96 BCA G96 N Online in India

Buy the Dormakaba ITS 96 Concealed Door Closer BCA G 96 N Slide Arm EN 3–6 from That Hardware Store for architectural, residential and commercial door applications.

Whether you are looking for a Dormakaba door closer, Dorma door closer, Dorma concealed door closer or a premium Dorma door closer concealed within the door and frame, the ITS 96 BCA provides a discreet and highly adjustable door-control solution.

For project requirements, door compatibility, installation configuration and current dorma door closer price, contact our team for assistance in selecting the appropriate Dormakaba door closer and accessories.

Choose the Dormakaba ITS 96 BCA G 96 N when you need concealed installation, adjustable EN 3–6 closing performance and hydraulic backcheck in one premium door-control system.
